JIS KBS GROUP® BAND SAW BLADES

Slide 1
Slide 2
STEEL GRADE CHEMICAL COMPOSITION %
C Mn Ni Cr
JIS SK85M 0.85 0.30 - 0.15
JIS SKS51M 0.80 0.30 1.35 0.25
STANDAED SIZES
Thickness Width (inch) Hardness
BWG (mm) 8 7 6 5 4½ 4 3 2 1 (HRC)
17 1.47 ● ● 45
18 1.25 ● ● ● ● ● ● 45
19 1.05 ● ● ● ● ● 45
20 0.90 ● ● ● ● ● 46
21 0.80 ● ● ● ● 46

Customized thickness, width and hardness are also available upon request.
